Part Number |
BMQA00101040R33MD1
|
---|---|
Manufacturer | Pulse Larsen Antenna |
Other Part Numbers |
553-BMQA00101040R33MD1TR-ND
553-BMQA00101040R33MD1TR
|
Description | INDUCTOR POWER |
Detailed Description | 330 nH Shielded Molded Inductor 32 A 0.68mOhm Max Nonstandard |
Datasheet | Datasheet |
Category | ||
---|---|---|
Manufacturer | Pulse Larsen Antenna | |
Series |
BMQx
|
|
Packaging |
Tape & Reel (TR)
|
|
Part Status | Active | |
Tolerance | ±20% | |
Package / Case | Nonstandard | |
Size / Dimension | 0.445" L x 0.402" W (11.30mm x 10.20mm) | |
Mounting Type | Surface Mount | |
Shielding | Shielded | |
Type | Molded | |
Operating Temperature | -55°C ~ 125°C | |
DC Resistance (DCR) | 0.68mOhm Max | |
Current - Saturation (Isat) | 45A | |
Inductance Frequency - Test | 100 kHz | |
Height - Seated (Max) | 0.157" (4.00mm) | |
Inductance | 330 nH | |
Current Rating (Amps) | 32 A |
RESOURCE TYPE | LINK | |
---|---|---|
Datasheets | BMQA00101040R33MD1 | |
Environmental Information | BMQx Series Test Report | |
Environmental Information | BMQx Series, RoHS/REACH |
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8504.50.8000 | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
REACH Status | REACH Unaffected | |
RoHS Status | ROHS3 Compliant |
