LD2-122-HV

Part Number
LD2-122-HV
Manufacturer PowerStor (Eaton)
Other Part Numbers
283-LD2-122-HVTR-ND
283-LD2-122-HVTR
-875-LD2-122-HVCT
Description IND DRUM CORE 1200UH 0.33A
Detailed Description 1.2 mH Unshielded Wirewound Inductor 400 mA 4.5Ohm Max Nonstandard
Manufacturer Standard Lead Time 13 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer PowerStor (Eaton)
Series
LD2-HV
Packaging
Tape & Reel (TR)
Part Status Active
Tolerance ±20%
Package / Case Nonstandard
Size / Dimension 0.307" L x 0.276" W (7.80mm x 7.00mm)
Mounting Type Surface Mount
Shielding Unshielded
Type Wirewound
Operating Temperature -25°C ~ 125°C
DC Resistance (DCR) 4.5Ohm Max
Current - Saturation (Isat) 330mA
Material - Core Ferrite
Inductance Frequency - Test 100 kHz
Height - Seated (Max) 0.209" (5.30mm)
Inductance 1.2 mH
Current Rating (Amps) 400 mA

Documents & Media

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.50.8000
Moisture Sensitivity Level (MSL) 1 (Unlimited)
RoHS Status ROHS3 Compliant

Available To Order
