SR1-0603-091

SR1-0603-091

Part Number	SR1-0603-091
Manufacturer	NTE Electronics, Inc.
Other Part Numbers	2368-SR1-0603-091-ND 2368-SR1-0603-091
Description	RES 91 OHM 5% 1/16W 0603
Detailed Description	91 Ohms ±5% 0.063W, 1/16W Chip Resistor 0603 (1608 Metric) Thick Film
Datasheet	Datasheet

Product Attributes

Category		Resistors Chip Resistor - Surface Mount
Manufacturer		NTE Electronics, Inc.
Series		SR1
Packaging		Bag
Part Status		Active
Power (Watts)		0.063W, 1/16W
Tolerance		±5%
Package / Case		0603 (1608 Metric)
Temperature Coefficient		±200ppm/°C
Size / Dimension		0.061" L x 0.031" W (1.55mm x 0.80mm)
Composition		Thick Film
Operating Temperature		-55°C ~ 155°C
Number of Terminations		2
Supplier Device Package		0603
Height - Seated (Max)		0.016" (0.40mm)
Resistance		91 Ohms

Documents & Media

RESOURCE TYPE		LINK
Datasheets		SR1-0603-091
Datasheets		RoHS Statement
Datasheets		REACH Statement

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8533.21.0090
RoHS Status		RoHS non-compliant
